Laser Equipment

Laser Equipment

CO2 Laser Cutting Machine

Large-format CO2 laser cutting for nonmetal sign and fabrication materials.

The TK-3015 CO2 laser cutting machine uses a sealed CO2 glass laser tube with water cooling and a 1500 x 3000mm working area for large-format nonmetal production.

Power
500W laser tube
Work area
1500 x 3000mm
Speed
0-3000mm/min
Accuracy
±0.05mm
Get Quote View Specifications
CO2 Laser Cutting Machine

Media

CO2 Laser Cutting Machine
CO2 Laser Cutting Machine
CO2 Laser Cutting Machine detail

Machine specifications

Machine Details

  • Control SystemRuida 8445 system
  • TransmissionY-axis rack transmission + reducer; X-axis belt transmission
  • Cutting HeadLifting cutting head
  • Guide RailTaiwan CSK guide rail
  • MotorLeadshine 758 hybrid servo motor
  • CoolingTeyu CW6000AN water chiller

Applicable Material

  • Nonmetal MaterialAcrylic, leather, rubber, plastic, granite, cloth, glass, wood plank, and paper
  • SamplesAcrylic cutting, plywood cutting, MDF cutting, wood engraving, and wood cutting
  • PlatformBlade platform
  • Auxiliary EquipmentRed dot, Haili 195W air pump, 550W fan, and tool box
Full technical specification17 items
Technical Specifications
Model1530
Working Size1500 x 3000mm
Laser Power500W laser tube
Laser TypeSealed CO2 glass laser tube, water cooling
Cutting Speed0-3000mm/min
Reposition Accuracy±0.05mm
Working VoltageAC110-220V±10% 50HZ-60HZ
Graphic FormatsDST, PLT, BMP, DXF, AI, CDR
SoftwareCorelDRAW, Photoshop, AutoCAD
Y-axis TransmissionTaiwan square linear guide rail
DriverYAKO driver
MotorStepper motor
Cooling TypeCW 6000 water chiller
Auxiliary EquipmentExhaust fans and air exhaust pipe
Operating Temperature0-45°C
Operating Humidity8%-95% without condensed water
Package MaterialFumigation material

Plan a CO2 laser workflow

Need help configuring TK-3015 for your materials?

Share your material list, sheet size, and expected throughput. Tekkaform can help confirm the right CO2 laser setup.

Request consultation
